Descripción
Especificaciones
- Dimensiones 216 x 140 x 54 mm
Interfaces
- de Red (8) 10/100/1000Mbps (PoE 24/48V ajustable)
- (2) SFP Gigabit
- Ventilador Fanless
- Consumo de Energía 150 W (Max. con dispositivos PoE conectados)
- 10 W (Sin salida PoE)
- Fuente de alimentación externa AC 110~240V 50/60 Hz
- DC 48-55V 5A Max
- Puertos PoE (RJ45) Port1-8: 802.3af/at PoE o 24 V PoE Pasivo
- Bandwidth 20Gbps
- Mac Address Table 8K
- Packet Forwarding Rate 14.9Mpps
- Protection Level Lightning protection 6KV
- 6KV ESD Contact discharge
- Tempreratura de Operación -10 to 55° C
- Certificaciones CE, FCC, RoHS
Características
- QoS Soporta 802.1p CoS/DSCP priority
- 4 colas de prioridades
- Capa 2 IGMP Snooping V1/V2/V3
- 802.3ad LACP (hasta 8 grupos)
- Spanning Tree STP/RSTP/MSTP
- Port Isolation
- VLAN Soporta hasta 4K VLANs
- Port/ MAC/Protocol-based VLAN
- VLAN de gestión
- Access Control List L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID
- Seguridad IP-MAC-Port-VID Binding
- IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
- SSH v1/v2
- Administración Web-based GUI and CLI management
- SNMP v1/v2c/v3,compatible with public MIBs
- DHCP/BOOTP Client,DHCP Snooping,DHCP Option82
- CPU Monitoring
- Port Mirroring
